This mode allows you to control your heater or furnace. To use the heat mode, you will select your preferred minimum temperature. Any time the air in your home dips below this temperature, the thermostat will turn on the heater. Most people will use the heat mode when they are cold in the winter, fall, or spring.

White is the snow that makes the house cold, w for heat. Red is the transformer that caught fire when you neglected to turn the power off prior to changing the thermostat. R for hot wire. Green is the color of money, which leaves your bank account each time you hear the fan running to heat and cool your home. Most thermostats follow the same standard lettering system. However, the instructions provided below are not universal. In order to avoid any mistakes, it is always better to consult the diagram provided by the manufacturer. Each letter basically corresponds with the wire clot, ie. Y = yellow, g = green, r=red, w = white.
